Подвесной полосковый фильтр нижних частот

Serial

Parameters

1

Cut Off Frequency

20GHz

2

Pass Band Frequency

DC～20GHz

3

Pass Band Insertion Loss

≤1.0dB @ DC～19GHz

≤3.0dB @ 19～20GHz

4

Pass Band VSWR

≤1.6:1

5

Stop Band Attenuation

≥50dB @ 21.2～27GHz

6

Impedance

50 ohms

7

Power

≤15W

8

Connectors

SMA-Female

9

Surface Finish

Guided Oxygen or Black Paint

10

Temperature Range

-55℃～+85℃

11

Net weight

0.0135 KG

12

Size

17*17*10mm
