技术数据
|
S/N |
Item |
Parameters |
|
|
1 |
Cut Off Frequency |
8.0GHz |
|
|
2 |
Pass Band Frequency |
8.0 ~ 28GHz |
|
|
3 |
Pass Band Insertion Loss |
≤1.5dB @ 8.0 ~ 8.3GHz ≤1.0dB @ 8.3 ~ 28GHz |
|
|
4 |
Pass Band VSWR |
≤1.5:1 |
|
|
5 |
Stop Band Attenuation |
≥50dB @ DC ~ 6.65GHz |
|
|
6 |
Impedance |
50 Ohms |
|
|
7 |
Power Handling |
15W Max. |
|
|
8 |
Connectors |
SMA-Female |
|
|
9 |
Surface Finish |
Guide Oxygen or Painted Black |
|
|
10 |
Temperature Range |
-55℃ ~ +85℃ |
|
|
11 |
Material |
Housing: 6061 Aluminum alloy Connectors: Stainless Steel |
screw: Stainless Steel |
|
12 |
Dimensions |
19*15*10mm |
|
|
13 |
Net weight |
0.015 KG |
|
